5-2. Replacing Refrigerator Parts
1) Deodorizer
2) Top R-Light
* Turn deodorizer counterclockwise.
(Assembling is the reverse order of disassembling.)
* Like F-lights, remove two screw caps at the bottom
of light cover with a (-) driver.
* Unscrew two screws with a (+) driver.
* Pull down R-light cover a little to separate the hook
and pull out forward smoothly.
* Replacing the bulb.
(Assembling is the reverse order of disassembling.)
- 47 -
