6) Return Duct Cover
7) Dairy Pocket
8) Refreshment Pocket (Only for FRS-2041)
9) Refrigerator interior parts
* Pull out the cover to arrow direction.
* Pull forward and lift up a little.
* Hold both end and pull up to remove the pocket.
* Lift up a little and then pull forward out.
* Remove foods and shelves of R-compartment.
* Remove screws caps with a tiny tip screw driver and
remove light cover screws with a (+) screw driver
(Refer to 2) Top R-Light)
* Disassemble RAMP R A HOUSING, SENSOR HOUSING
and RAMP R B HOUSING.
- 49 -
