Removing of Check Valve
Failure Checkup & Troubleshooting
* Remove foods and shelves of R-
compartment.
* Remove screws caps with a tiny tip
screw driver.
Remove light cover screws with a
(+)screw driver.
Hold the bottom of cover to pull down.
Disconnect light housing.
Hold the bottom and right
of damper to pull down to
remove.
Lift up a piece of Check Valve Flap
and insert a finger to the valve frame
to hold out.
Page 14
1
8
2
7
6
5
3
4
Remove screws with a
(+) screw driver.
To Next Page
