Forced Defrosting
INPUT Control Object
1. “FRZ SET. ” button
2. “REF SET. ” button
3. “LOCK” button
Defrosting Mode
CONTENTS REMARKS
1. How to start
-> Set “LOCK ON” first, then push “REF SET.” button 5 times while
pushing “FRZ SET. ” button simultaneously.
2. How to proceed
1) Delete Pre-cool mode. (Others are same as normal defrosting.)
2) Heater is ON regardless of D-sensor temp. at first 30 seconds.
( Check of defrosting current)
6-11. Initial Defrosting
INPUT Control Object
D-sensor
Initial or first power input (power plugin)
Defrosting Mode
CONTENTS REMARKS
If D-sensor temp. < 3.5C, defrosting mode starts from Pre-cool at first
power input.
Comp. is delayed for 6 min.
at the initial defrosting.
6-12. Buzzer or Alarm
INPUT Control Object
F-PCB buttons
Door Switch
Initial Power Input
BUZZER
CONTENTS REMARKS
1. Buzzer sounds if any button of F-PCB is pushed.
2. Buzzer sounds 3 times 3 minutes after initial power input.
3. Buzzer sounds for 1 second in case of A/S forced defrosting, short (pull-
down) operation, explanation mode.
4. If door is open, buzzer sounds continually 3 times for 5 seconds.
(Door open alarm)
LCD Background Light
INPUT Control Object
F-PCB buttons
Door Switch
Initial Power Input
LCD BACK LIGHT
- 30 -
=
