NO PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
3000003600 ASSY CAB URT 1 FRS-2021
3000025700 ASSY CAB URT FR-S690CG/CR FRS-2421
2 3012917600 HINGE *T *R AS PO T3.0 1
3 3012918500 HINGE *T *L AS PO T3.0 1
4 3012013000 FIXTURE *T HI PP 2
6 3011472400 COVER HI *T *R PP 1
7 3011472300 COVER HI *T *L PP 1
8 7112401211 SCREW TAPPING T1 TRS 4 x 12 MFZN 2
9 3012601301 HANDLE CAB COVR *R PP 1
10 3012601201 HANDLE CAB COVR *L PP 1
11 7112401211 SCREW TAPPING T1 TRS 4 x 12 MFZN 1
12 3010533400 BOX MAIN PCB PP 1
13 CAPACITOR RUN 1
14 PCB MAIN AS 1
15 3011472610 COVER MAIN PCB BOX PP 1
16 7112401211 SCREW TAPPING T1 TRS 4 x 12 MFZN 1
17 3012917810 HINGE *U *R AS PO T5.0+PAINTING 1
18 3012917710 HINGE *U *L AS PO T5.0+PAINTING 1
19 3012513300 GUIDE *U HINGE *U POM 2
20 7002501611 SCREW MACHINE TRS M5 x 16 MFZN 2
21 3016001240 SPECIAL BOLT *T 6 x 22 SWCH22A(YL) 8
22 3015306700 SUPPORTER *U HI AS PO T5.0 2
23 3012104400 FOOT ADJUST AS 2
24 3016501200 CASTER TURN AS TURN CASTER 2
25 3016001240 SPECIAL BOLT *T 6 x 22 SWCH22A(YL) 2
26 3011471010 COVER CAB BRKT PP 1
27 7142401611 SCREW TAPPING T2 TRS 4 x 16 MFZN 3
29 3010326700 BASE COMP AS SBHG T1.2 1
30 3016003300 SPECIAL BOLT T2 M6.5 x 20 4EA 4
31 CORD POWER AS 1
32 7112401211 SCREW TAPPING T1 TRS 4 x 12 MFZN 1
33 7051401065 SCREW MACHINE PAN 4 x 10 SW BSNI 1
34 COMP 1
35 3016002500 SPECIAL WASHER SK-5 T0.8 4
36 3010101440 ABSORBER COMP AS 4
38 RELAY STARTING 1
39 3011113500 CASE VAPORI PP + CTALC 1
40 3013201700 HOSE DRAIN PEHD 1
41 3014413730 PIPE WICON AS 1
42 3010102100 ABSORBER C MOTR NR FRB-5350NT 1
43 3012004400 FIXTURE C MOTR SUS 1
1
- 68 -
7-2. Total Parts List
FRS-2021 / FRS-2421
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
