6-1. Installation Preparation
Dimensions (Including Door Handles)
Sufficient space from refrigerator back to the
wall for free air ventilation
Avoid direct sunlight.
Once the installation place is ready follow the installation instructions.
If surround temperature of refrigerator is low (below 5C), foods can be frozen or the refrigerator can work
in an abnormal way.
Check if the refrigerator can pass
a doorway or enter a door first.
Find a suitable place to install.
6. INSTALLATION GUIDE
- 54 -
(Width X Depth X Height)
928mm X 816mm X 1808mm [FRS-2021 / FRS-2041]
928mm X 896mm X 1808mm [FRS-2421 / FRS-2441]
