7) Front Control Pannel
냉동실 MOTER HOUSING
SENSOR HOUSING
* Separate sensor housing
on the top of F-louber C.
* Hold the bottom nose of cover and pull
forward out smoothly.
* Insert a flat tip driver into the left down groove of panel frame and snap it out smoothly.
* Remove housing from F-PCB and screws on the board to change for a new one.
* Assembling is the reverse order of disassembling.
* Separate Moter Housing and remove three screws.
* In order to disassemble F-louver C, separate hook
with a (-) driver and pull out smoothly.
* Like F-louver C, remove F-louver D.
(Assembling order is the reverse of disassembling.)
- 49 -
