4. Dispenser Solenoid Valve (Dispenser Models Only)
1) Disassembling Procedure (Features are model dependent)
2) How to check Dispenser Solenoid Valve
HOW TO CHECK EACH PART
No No
5
Procedure Procedure
Disassemble the Cover dispenser Box As Disconnect 2 terminals and 2P Wire.
Unscrew and remove Cover Ice Flap.Unscrew to remove Box Dispenser Ice Shut.
14
Unscrew and remove Solenoid Valve.
Separate Front PCB connector.
(Features are model dependent.)
36
2
( Good ): 215 Ohm (+-10%)
(193 ~ 236 Ohm)
(Defective): Change the part.
( Good ): 96 Ohm (+-8%)
(88 ~ 104 Ohm)
(Defective): Change the part.
Check the resistance of
both terminals.
Check the resistance of
2 terminals with a Tester.
Flap Heater Assembly
Dispenser Solenoid Valve
Parts How to Check Remark
