3. Dispenser Micro Switch (Dispenser Models Only)
1) Disassembling Procedure (Features are model dependent)
2) How to check the Hose Ice Maker Tube As.
HOW TO CHECK EACH PART
; Check both terminals (Red circle) with a Multi-Tester.
(Test Mode : Resistance )
; (If defective) Exchage new one.
No No
Dispenser Button and pull up.
2
Insert (-) screw driver into bottom hole of
1
Pull out the Micro Switch.
( Be careful not to damage the hook. )
Procedure Procedure
OFF (Open)
Disconnected No Value
Tact Switch (Blue circle)
Some Value
Test ResultTermainals (Red circle)
ON (Close)
Connected
34
