✔ Caution
:
In this Manual, some parts can be changed for improving, their performance without notice in the parts list.
So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center
(http://svc.dwe.co.kr).
3. PCB LOCATION NO.
KOR-146H
1 BUZZER BZ1 BM-20K 3515600100 1
2C ARRAY CA1 7P(6) 1000PF M 50V CN6XB-102M 1
3 CAPACITOR ELEC EC1 50V RS 10UF CEXE1H100A 1
4 CAPACITOR ELEC EC2 25V RSS 1000MF CEXF1E102V 1
5 CONNECTOR WAFER CN1 YW396-02V 3519150520 1
6 CONNECTOR WAFER CN2 FCZ 254-11 441M367160 1
7 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
8 DIODE RECTIFY D1~5,D8~D12 1N4148 DZN4148--- 10
9 DIODE RECTIFY D13,14 KN4004A DZN4004A-- 2
10 DIODE ZENER ZD1 UZ- 3.3BSB 1/2W DZUZ3R3BSB 1
11 DIODE ZENER ZD2 UZ- 5.1BSB 1/2W DZUZ5R1BSB 1
12 LED DISPLAY DP1 TOF-4461BG-B10 DT0F4461BG 1
13 PCB MAIN M338 81.5X139.9 3514315430 1
14 R ARRAY RA1 8P(7) 1/8 100K OHM J RA-88X104J 1
15 R ARRAY RA2 7P(6) 1/8 100K OHM J RA-87X104J 1
16 RESISTOR R2~8 1/6W 330 5% RD-AZ331J- 7
17 RESISTOR R1,10,12,17,18,22 1/6W 1K 5% RD-AZ102J- 6
18 RESISTOR R13,R19,20 1/6W 10K 5% RD-AZ103J- 3
19 RESISTOR R9 1/6W 100K 5% RD-AZ104J- 1
20 RESISTOR R11 1/6W 200 5% RD-AZ201J- 1
21 RESISTOR R14 1/6W 1M 5% RD-AZ105J- 1
22 RESISTOR R21 1/4W 51 5% RD-4Z510J- 1
23 RESONATOR CERA CR1 CRT 4.00MS 5P4R00MTS- 1
24 IC REGULATOR VL1 MC7805C 1CPMC7805C 1
25 TRANSISTOR Q1~5 KRA106M TZRA106M-- 5
26 TRANSISTOR Q9~11 KRC106M TZRC106M-- 3
27 TRANSISTOR Q6 KTA-1266Y TZTA1266Y- 1
28 CAPACITOR CERA C5 102 50V Z AXIAL CCZB1H102K 1
29 CAPACITOR CERA C1~4,C6~7 104 50V Z AXIAL CCZF1H104Z 6
30 TRANS POWER LVT1 DMR-631P 5EPU035302 1
31 WIRE COPPER J1~J10,J13,J14 1/0.52 TIN COATING 85801052GY 12
32 WIRE COPPER SJ1,SJ3,SJ4 1/0.52 TIN COATING 85801052GY 3
33 WIRE COPPER J11,J12 1/0.52 TIN COATING 85801053GY 2
34 SW RELAY RY1 G5G-1A DC12V 5SC0101121 1
35 SW RELAY RY2 OJ-SS-112LM 1C 1P 5SC0101404 1
36 IC MICOM IC1 HMS81C1716B-HNXXX 150LC1716B 1
NO NAME SYMBOL SPECIFICATION PART CODE Q’TY
