46
NO NAME SYMBOL SPECIFICATION PART CODE Q’TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 C ARRAY CA1 7P(6) 1000PF M 50V CN6XB-102M 1
3 CAPACITOR CERA C1 50V F 0.047MF Z CCZF1H473Z 1
4 CAPACITOR CERA C2~6 50V HIKF 0.1MF Z CCZF1H104Z 5
5 CAPACITOR ELEC EC1 16V RSS 100MF CEXF1C101V 1
6 CAPACITOR ELEC EC2 25V RSS 1000MF CEXF1E102V 1
7 CONNECTOR WAFER CN1 YW396-02V 3519150520 1
8 CONNECTOR FILM CN2 FCZ 254-11 441M367160 1
9 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
10 DIODE RECTIFY D4~6 1N4148M DZN4148M-- 3
11 DIODE RECTIFY "D1~3,8,9,11,12" 1N4148 DZN4148--- 7
12 DIODE RECTIFY "D13,14" 1N4004A DZN4004A-- 2
13 DIODE ZENER ZD1 UZ- 3.3BSB 1/2W DZUZ3R3BSB 1
14 DIODE ZENER ZD2 UZ- 5.1BSB 1/2W DZUZ5R1BSB 1
15 IC MICOM IC1 HD404054A47S 147S121MQ0 1
16 IC REGULATOR VL1 MC7805C 1CPMC7805C 1
17 LED DISPLAY DP1 DDG-611Q DDDG611Q00 1
18 PCB MAIN M152 81.5X139.9 3514315400 1
19 R ARRAY RA1 7P(6) 1/8 100K J RA-87X104J 1
20 RESISTER R12 1/6W 100 5% RD-AZ201J- 1
21 RESISTER "R11,15,17,24" 1/6W 1K 5% RD-AZ102J- 4
22 RESISTER R21 1/6W 4.7K 5% RD-AZ472J- 1
23 RESISTER "R13,16,22" 1/6W 10K 5% RD-AZ103J- 3
24 RESISTER "R10,18~20" 1/6W 100K 5% RD-AZ104J- 4
25 RESISTER R14 1/6W 1M 5% RD-AZ105J- 1
26 RESISTER R1~9 1/4W 330 5% RD-4Z331J- 9
27 RESISTER R23 1/4W 51 5% RD-4Z510J- 1
28 RESONATOR CERA CR1 CRT 4.00MS 5P4R00MTS- 1
29 SW RELAY RY2 G5J-1-TP-M12V 5SC0101108 1
30 SW RELAY RY3 CS11-12SH 1C 1P 5SC0101128 1
31 TRANSISTOR Q1~5 KRA-110M TZRA110M-- 5
32 TRANSISTOR "Q6~8,11~13" KRC-106M TZRC106M-- 6
33 TRANSISTOR Q9 KTA-1266Y TZTA1266Y- 1
34 TRANS POWER LVT DMR-602P 5EPU035406 1
35 WIRE COPPER "J1~5,9" 1/0.52 TIN COATING 85801052GY 6
36 WIRE COPPER "J6~8,10" 1/0.52 TIN COATING 85801052GY 4
37 WIRE COPPER "SJ2,SJ3" 1/0.52 TIN COATING 85801052GY 2
3. PCB LOCATION NO.
