Daewoo MC-5210SU - Part List; Continuation of Component List

MAIN PCB
ASSY
2 57 C1. 127-228058-01 E.CAP ELE.CAP 2200UF/25V +80/-20% 1
MAIN PCB
ASSY
2 58 L2. 105-104101-63 Inductance
JHHI1608C100nJT(0603-100nH+/-
5%)
1
MAIN PCB
ASSY
2 59 FOR IN4002 C01-010000-00 TUBE PVC 1MM TUBE L =10MM 8
MAIN PCB
ASSY
1 60 Main 190-800821-01 PCB Board
USB8008PR MB PCB 94V0料
1
DISPLAY PCB
ASSY
1 12000 158-800822-01 DISPLAY PCB ASSY USB8008PR DISPLAYER ASS’Y 1
DISPLAY PCB
ASSY
2 1 IC1. (USB8008PPRS) 133-008008-06 IC
IC Style：CA6808F (checkout code：
001D42C5)
1
DISPLAY PCB
ASSY
2 2 U1 133-024C02-1A IC I C AT24LC02N SMT 1
DISPLAY PCB
ASSY
2 3 Q1. 131-457533-13 IC
VOLTAGE REGULATOR HT7533-
1(TO-92)
1
DISPLAY PCB
ASSY
1YALPSID DCLYALPSID DCL?-531.1DCL42
DISPLAY PCB
ASSY
2 5 LED1. 187-412110-01
DISPLAY
BACKGROUND
LIGHT
1PID-1B2250HF
DISPLAY PCB
ASSY
2 6 LCD1. 135-800800-00 LCD DISPLAY
LCD DISPLAY DNI-3127--B
(8008PR)
1
DISPLAY PCB
ASSY
2 7 LED1. 187-412110-04
WHITE
BACKGROUND
LIGHT
1PID-1W2250HF
DISPLAY PCB
ASSY
2 8 Y1. 137-327680-20 CRYSTAL
32.768KHz（SIZE：3X8mm）,+/-
10PPM
1
DISPLAY PCB
ASSY
2 9 S6-13 147-110143-00 TACT SWITCH
TACT SWITCH H:4.3MM/4
TERMINAL
8
DISPLAY PCB
ASSY
2 10
AVOL1 （Same as
UC899PR）
111-899001-00 SWITCH F-12EN5H24B+C L20FX7(D) 1
DISPLAY PCB
ASSY
2 11
J1-10.13.15.16.18.19.23-
25.27-29.
C16-005000-00 JUMPER WIRE JUMPER WIRE 40*0.5MM 22
DISPLAY PCB
ASSY
2 12
Q2.4.5.(Remark:Use
good quality)
131-448050-1A TRANSISTOR TRANSISTOR 2SD8050 SMT 3
DISPLAY PCB
ASSY
2 13
Q3.(Remark:Use good
quality)
131-448550-1A TRANSISTOR TRANSISTOR 2SD8550 SMT 1
DISPLAY PCB
ASSY
2 14 D3.4.6.8. 130-344148-7D DIODE DIODE LL4148 (LL-34) 4
DISPLAY PCB
ASSY
2 15 D2. 130-340033-7D DIODE ZENER DIODE ZMM3V3 (LL-34) 1
DISPLAY PCB
ASSY
2 16 D1. 130-340068-7D DIODE ZENER DIODE ZMM6V8 (LL-34) 1
DISPLAY PCB
ASSY
3EULB4*3*2-YGDEL31-339232-031.5.4.3DEL712
DISPLAY PCB
ASSY
1A3-NL8303 MFKCAP RENUT00-830313-6311MER812
DISPLAY PCB
ASSY
2 19 R53. 113-102005-63 C.RESISTOR CAR. RESISTOR 1K 0603 1
DISPLAY PCB
ASSY
2 20 R54. 113-473005-63 C.RESISTOR CAR. RESISTOR 47K 0603 1
DISPLAY PCB
ASSY
2 21 C12. 123-560340-63 C.RESISTOR C.CAP 56PF NPO 50V 0603 1
DISPLAY PCB
ASSY
2 22 R46. 113-000005-63 C.RESISTOR CAR RESISTOR 0 OHM 0603 1
DISPLAY PCB
ASSY
2 23 R13. 113-100005-63 C.RESISTOR CAR RESISTOR 10 OHM 0603 1
DISPLAY PCB
ASSY
2 24
J12
2012-06-14
113-000005-26 C.RESISTOR CARBON RESISTOR 0 OHM (1206) 1
DISPLAY PCB
ASSY
2 25 R52. 113-100005-85 C.RESISTOR CAR. RESISTOR 10 OHM 0805 1
9
9
