9
5-4. DUST COVER ASSEMBLY
NO PART NAME PART CODE SPEC. Q TY
1 COVER DUST 3621417900 ABS KR-2870 1
2 CLAMP COVER 3621202000 ABS KR-2870 1
3 SPRING CLAMP 3625106400 HSW3 1
4 HOUSING DM 3626100300 GPPS 1
5 DUST METER 3629702100 ABS 1
6 CAP DM 3620903500 LDPE 1
7 SPRING DM 3625106300 SUS 1
8 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN 1
9 COVER TOP 3621417100 PP 1
10 BUTTON POWER 3626603600 ABS 1
11 BUTTON CR 3626603700 ABS 1
12 SPRING 3625103400 HSW3 CR BUTTON 2
13 HANDLE 3622601400 PP 1
14 SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN 2
