Daewoo RC-4005B'S - 5 Disassembling and Treatment; Cleaner Assembly

5. DISASSEMBLING AND TREATMENT
1) LIFT THE DUST COVER(8), GRILLE(10), FILTER(9) AND UNSCREW THE 6 SCREWS(6)
AND THEN LIFT THE COVER ASSEMBLY(5) UP FROM THE BODY ASSEMBLY(1).
2) CHECK THE DUST BOX.
3) CHECK THE HEPA(OR GENERAL) FILTER (9).
5-1. CLEANER ASSEMBLY
7
