Daewoo RG-361 - Page 21

PARTS LIST
DATE:2005-1-25
AM:522-1620KHz
FM:88-108MHZ
Item
Part NO Qty
PROPOSE
Description
Model No:RG-361
REF NO:KW-EP-0171<REV:A0>
95
CAP. (SMD0603):<25V>(+/-5%)
96
211-0010PDA-BS 10pf 1 C3
97
211-0100PDA-BS 100PF 3
C4 C24 BC5
98
211-0390PDA-BS 390pf 3 C51 C45 C64
99
211-0330PDA-BS 330pf 1 C84
100
211-0680PDA-BS 680pf 2 C85 C86
101
CAP .(SMD0603):<25V>(+/-10%)
102
211-0U001DB-BS 102pf(0.001uf) 2 C66 C53
103
211-00U01DB-BS
103（0.01uf)
5 C58 C59 C65 C46 C60
104
CAP. (SMD0603):<25V>(+80-20%)
105
211-U0022DD-BS 222(0.0022uf) 1 C49
106
211-U0047DD-BS 472(0.0047uf) 1 C63
107
211-U0056DD-BS 562(0.0056uf) 1 C57
108
211-0U033DD-BS 333(0.033uf) 2 C68 C44
109
211-0U068DD-BS 683(0.068uf) 1 C41
110
211-00U15DD-BS 154(0.15uf) 1 C40
111
211-00U47DD-BS 474(0.47uf) 3 C55 C56 C69
112
211-000U1DD-BS 104(0.1uf) 22
C13 BC31 C22 BC8 C26 C87 BC19 C2 C67
C73 C74 C28 C82 C76 C79 C43 C25 C20
C17 C19 C39 C5
113
ELECT CAP.:+/-10%
114
212-0001UFB-1S 1uf/50v
2 TC30 TC31
115
212-004U7FB-1S 4.7uf/50v 1 C71
116
212-0010UDB-1S 10uf/25v 4 C42 TC6 TC17 TC23
117
212-0100UCC-1S ELECT CAP. :+/-
2
100uf/16v 12
C78 TC29 C6 C77 C61 C48 C27 C30 C83 TC8
TC1 TC2
118
212-0220UCC-1S 220uf/16v 1 C1
119
212-1000UCC-1S 1000uf/10v 1 C75
120
RESISTOR(SMD0603): +/-5%
121
201-0000RDA-B1 0 OHM 32
JR34 JR5 JR24 JR25 JR30 JR32 JR2 JR3
JR9 JR27 JR11 JR21 JR23 JR22 JR7 JR8
JR26 JR1 JR28 JR12 JR13 JR19 JR6 JR31
JR10 JR16 JR17 JR14 JR20 JR18 JR15
JR29
122
201-0010RDA-B1
10 OHM
1 R65
PAGE 21 ,TOTAL 31
