Daewoo RG-361 - Page 22

PARTS LIST
DATE:2005-1-25
AM:522-1620KHz
FM:88-108MHZ
Item
Part NO Qty
PROPOSE
Description
Model No:RG-361
REF NO:KW-EP-0171<REV:A0>
123
201-002R2DA-B1 2.2 OHM 2 R4 R68
124
201-0082RDA-B1 82 OHM 1 R71
125
201-0100RDA-B1 100 OHM 1 R96
126
201-0220RDA-B1 220 OHM 2 R1 R5
127
201-0270RDA-B1 270 OHM 1 R11
128
201-0330RDA-B1 330 OHM 1 R18
129
201-0560RDA-B1 560 OHM 1 R6
130
201-0820RDA-B1 820 OHM 1 R9
131
201-0001KDA-B1 1K OHM 3 R102 R103 R17
132
201-002K2DA-B1 2.2K OHM 2 R111 R19
133
201-004K7DA-B1 4.7K OHM 11
R14 R2 R7 R25 R67 R41 R42 R43 R44
R81 R12
134
201-0010KDA-B1 10K OHM 3 R3 R87 R22
135
201-008K2DA-B1 8.2 K OHM 1 R85
136
201-0018KDA-B1 18K OHM 1 R83
137
201-0012KDA-B1 12K OHM 2 R88 R84
138
201-0022KDA-B1 22K OHM 1 R61
139
201-0047KDA-B1 47K OHM 6 R59 R62 R72 R73 R74 R77
140
201-0068KDA-B1 68K OHM 1 R52
141
201-0082KDA-B1 82K OHM 4 R75 R63 R78 R80
142
201-0100KDA-B1 100K OHM 7 R56 R69 R64 R97 R100 R101 R76
143
201-0120KDA-B1 120K OHM 1 R53
144
201-0180KDA-B1 180K OHM 1 R86
145
201-0001MDA-B1 1M OHM 1 R89
146
361-5003000-00
光线：Φ0.5x30mm
60
AMP PCB
1
271-K105CPO-11 PCB:
KW-105AD POWER 94HB
(W58mmxD58mm) H:1.6mm
1
2
100-UTC8227-10 IC: UTC8227 1
IC5
3
111-IN53921-00
DIDOE:
IN5392 4 D501 D502 D503 D504
4
322-3507SW2-A0
PHONE JACK:
3507-202 1 JACK2
5
322-3503001-A0 3.5mm JACK EJ-3503 2 JK3 JK4
6 CAP.: 50V (+80/-20%)
PAGE 22 ,TOTAL 31
