PARTS LIST
DATE:2005-1-25
AM:522-1620KHz
FM:88-108MHZ
Item
Part NO Qty
PROPOSE
Description
Model No:RG-361
REF NO:KW-EP-0171<REV:A0>
7 211-0U001FD-1S 102(0.001uf)
2 C1 C2
8 211-00U02FD-1S 203(0.02uf)
4 C501 C502 C503 C504
9 211-000U1FD-1S
104(0.1uf) 2 C211 C212
10
212-0047UCC-1S ELECT CAP.:(+/-
2
47UF/16V 3 C205 C206 C210
11
212-0100UCC-1S 100UF/16V 2 C202 C209
12
212-0470UBC-1S
470UF/10V
2 C213 C214
13
212-1000UDC-1S
1000UF/25V
1 C215
14
212-2200UDC-1S 2200UF/25V 1 C505
15
201-0001RDA-11
RESISTOR:1/8W
1 OHM 2 R205 R206
16
201-0220RDA-11 220 OHM 4 R203 R204 R501 R502
17
201-0010KDA-11 10K OHM 2 R55 R56
18
294-46UH02B-00 CHOKE COIL: 46UH 3 L1 L2 L3
19
294-8UH002B-00 CHOKE COIL: 8UH 3 SPEAKER TO PCBx3
20
451-KT20600-00
FUSE HOLDER:
2
21
261-F250012-01
FUSE:
T 2.5A/250V 1
22
526-0181000-00
OIL PLATE:
Φ1.8x10mm
8
23
271-K105CPO-11 PCB: KW-105CD AMP PCB
1
24
331-0620181-00 (2.0mmHSG) 6PIN (Y-INTE.) 1
25
491-KW89C4B-00
HEATSINK
KW-89 8227 PLATE 1
26
481-0000230-00
EYELET:
2x3 2
27
245-K105MTA-70 LCD DISPLAY::
KW-105AD/MP3 7X8 ANL:+70/20℃
1
28
113-033004A-00 LED:
Φ3mm GREEN L=30MM
1 LED1
29
113-053003B-00
Φ5mm FLAT BLUE L=30MM
2 LED2 LED3
30
105-2031T15-00
REMOTE RECEIVER（5V）
1
31
314-KW98C25-00
ELECTRONICS POTENTME
T
R1615G12 A1 L=25MM 1 VR1
32
291-120020A-04 AM COIL:
120：20T（3+1） L=125mm
1
33
452-0010301-00
MANGET BRACKET:
Φ10x30mm
2
34
371-1006001-00 MAGNET:
Φ10x60mm
1
35
502-2515100-00 FERRITE COIL: 25x15x10mm 2 TRANSFORMER 3.5Tx1 AMP PCB5Tx1
36
502-1810060-00 FERRITE COIL:18x10x6mm 2
TRANSFORMER 3.5Tx1 AMP PCB
3
Tx1
