Daewoo RG-361 - Page 24

PARTS LIST
DATE:2005-1-25
AM:522-1620KHz
FM:88-108MHZ
Item
Part NO Qty
PROPOSE
Description
Model No:RG-361
REF NO:KW-EP-0171<REV:A0>
37
502-1810120-00 FERRITE COIL :18x10x12mm 2 CD PCB 3Tx2
38
502-1508280-00 FERRITE COIL :15x8x28mm 1 RECORD PCB X1t
39
502-1307070-00
FERRITE COIL : Φ13mmx7.5mmx7mm
1 FM WIRE
40
215-1262001-00
VARIABEL CAP.：
126PF/20PF 1 PVC1
41
2.0mm HSG UL
42
341-K105MDU-A1
28# 4PIN 1HSG L=280mm 1
KEY PCBx1 COIL: 18x10x6mm ROUND 3T
43
341-K105MFU-A0 28# 6PIN 1HSG L=200mm 1
DISPLAY X 1
44 341-K105MGU-A1
28# 7PIN 1HSG L=250mm 1
REC PCBx1 W/ MAGNET 15x8x28mm ROUNF 1T
45 341-K105MFU-A3
26#
6PIN1HSG L=550mm
1
AMP PCBx1 COIL: 25x15x10mm ROUND 5T
46 341-K105MFU-A4
26#
6PIN 1HSG SHIELD CABLE 26#WIRE
L=500mm.L=600mm)26#WIRE L=500mm
1
CD PCBx1 , SHIELD CABLE R:18x10x12mm R:3T
6XWIRE R:18x10x12mm R:3T
47
819-K105C01-10 PLASTIC: KW-105 BULD HOLDER 1
48
915-K105C00-10
RECEIVER BRACKET
1
49
842-K105C05-20 LED BRACKET 1
50
471-0260681-00
SCREW:
MS/KH 2.6x4(Φ4.1mm) 2 PVCx2
51
527-6402700-00 FILTER PAPER: 46mmx27mmx0.18mm 1
52
524-K105M03-10 SHIELD PAPER: (0.3mm)45mmx80mm 1
53
111-IN41481-00
DIDOE:
IN 4148 1 RADIO POWER SUPPLYx1
54
CAP.:<50V>(+80/-20%)DIP
55
211-00U01FD-1S 103(0.01uf) 1 MAIN PCB (EMC)x1
56
WIRE: UL 28#
57
343-0030E2U-00 BLACK 30MM 2 LEDx1 SHIELD PAPERx1
58
343-0030E3U-00 RED 30MM 1 LEDx1
59
343-0070EGU-00 GREEN 70MM 1 MAIN PCB WIREx1
60
388-KW89M08-00 REMOTE CONTROL 1
61
RECORD PCB
62
100-AN73120-10 IC: AN7312 1 IC6
63
271-K105CPR-11 PCB:
KW-105AD PREAMP <94HB>
(W77mmxD43mm xH1.6mm)
1
64
311-PS6P2T0-00 RECORD SWITCH PS6P2T 1 SW10
65
112-6V81210-00 ZENER DIDOE: 6.8V 1 D11
66
RESISTOR 1/4: +/-5% (DIP)
PAGE 24 ,TOTAL 31
