Daewoo RL-411 - Page 27

Loc. Part Code Part Name Description Remark
B801 9CD6595500 PCB MAIN 220X186X1.6T
C401 CCXF1H104Z C CERA 50V F 0.1MF Z
CE201 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE202 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE203 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE204 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CE205 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CE206 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CE207 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
CE208 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CE209 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE210 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE211 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CE212 CEXF1E101V C ELECTRO 25V RSS100MF (6.3X11) TP
CE214 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE215 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CE220 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CE221 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE222 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CE270 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP RDS Model Only
CE401 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
CE402 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
CE403 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
CE404 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
CE405 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE406 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE407 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CE408 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE409 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE410 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE411 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE413 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE414 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE415 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE504 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE507 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE609 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CE615 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CE654 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
CE657 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
CE801 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE802 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CE803 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
CE804 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
CE805 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE806 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
CE807 CEXF1H470V C ELECTRO 50V RSS 47MF (5X11) TP
CE808 W581GY6095 wire jumper 6mm
CE809 CEXF1E101V C ELECTRO 25V RSS100MF (6.3X11) TP
CE810 W581GY6095 wire jumper 6mm
CE811 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CE901 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE902 CEXF1V102V C ELECTRO 35V RSS1000MF (13X25)
CEXF1H222V C ELECTRO 50V RSS 2200MF (16X35) RL-412/412G Only
CEXF1V222V C ELECTRO 35V RSS 2200MF (16X31.5) RL-411/411G Only
CE905 CEXF1H471V C ELECTRO 50V RSS 470MF (10X20) TP
CE911 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE912 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE913 CEXF1C331V C ELECTRO 16V RSS 330MF(8X11.5) TP
CE914 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE915 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
PCB MAIN ASS'Y [9CDC072900] : RL-412
CE904
