Loc. Part Code Part Name Description Remark
5LX159P829 COIL BEAD 1.5UH MIN Full FTZ Only
W581GY1005 WIRE JUMPER AWG 22 1/0.65 SN10 AUTO Simple FTZ Only
L510 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5 MM)
L520 5CPZ101K02 COIL PEAKING 100 UH K (AXIAL 3.5 MM)
Q501 KZTA1504-- TR KTA1504
Q502 KZTA1266Y- TR KTA1266
Q503 TKTD2058Y- TR 2SD2058
R551 RD-2Y229J- R CARBON FILM 1/2W 2.2 OHM J
R562 W581GY7595 R CARBON FILM AWG 22 1/0.65 SN7.5 AUTO
R590 RD-2Y229J- R CARBON FILM 1/2W 2.2 OHM J
XC501 5PQZTT1693 RESONATOR CERA QTTT16.93MMX(3PIN)
SW501 5S40101A01 SW PUSH LOCK R8120125
Loc. Part Code Part Name Description Remark
B505 9CD6596200 PCB MP3 123X115X1.6T
CE501 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE502 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE503 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE504 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE505 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE506 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE507 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE508 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE509 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CE510 CEXF1A102V C ELECTRO 10V RSS 1000MF TP
CE511 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE512 CEXF1C101V C ELECTRO 16V RSS100MF (6.3X11) TP
CE513 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CE515 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CW501 9CD6259300 CONN WAFER 52807-1610 SIDE ENTRY
CN506 9728826600 CONN AS 6P 110MM P=2.0 BOARD IN
CW504 9CD6264100 CONN WAFER FPC P=1.25 15P STRIGHT
CN507 9728826700 CONN AS 3P 80MM P=2.0 BOARD IN(UL1007#26)
CW705 9728827000 CONN WAFER PH-2A (P=2.0 2P)
CW505 9728826500 CONN WAFER PH-6A (P=2.0 6P)
CN504 9728826400 CONN AS FFC 16P P=1.0 X 120MM D
CN705 9728827000 CONN AS UL1007 #26 P=2.0 110MM 2P
D501 DRLZ3R9B-- DIODE ZENER CHIP RLZ3.9B
HC501 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC502 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC503 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
HC505 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
HC506 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
HC507 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
HC508 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 1608
HC511 HCQK409DBA C CHIP CERA 50V CH 4PF D 1608
HC512 HCQK100JBA C CHIP CERA 50V CH 10PF J 1608
HC513 HCBK682KBA C CHIP CERA 50V X7R 6800PF K 1608
HC514 HCBK472KBA C CHIP CERA 50V X7R 0.0047MF K 1608
HC516 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC517 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC518 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
HC519 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC520 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
HC521 HCBK474KBA C CHIP CERA 50V X7R 0.47MF K 1608
HC522 HCBK332KBA C CHIP CERA 50V X7R 3300PF K 1608
HC523 HCBK474KBA C CHIP CERA 50V X7R 0.47MF K 1608
HC524 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
HC525 HCBK683KBA C CHIP CERA 50V X7R 0.068MF K 1608
HC527 HCBK823KBA C CHIP CERA 50V X7R 0.082MF K 1608
HC528 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
PCB MP3 ASS'Y [9CDC073100] : RG-411/412
