32L Electric Oven with Hot Plates
Model No. SDA1609
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before first use of your Oven
• Remove all packing materials and discard responsibly.
• Ensure all parts are present - see Description of Parts below.
• Check that there is no transit damage to the mains cable or product.
• Make sure the Oven is unplugged and all the Timer Control (6) is set to the “0”
position.
• Place the Oven on a solid, level, non-flammable surface that is strong enough
to support the weight of the oven.
• Wash all the accessories (10-12) in warm soapy then rinse and dry thoroughly.
2
10
11
12
1. Large Hot Plate
2. Small Hot Plate
3. Hot Plate Control
4. Temperature Control
5. Oven Function Control
6. Timer Control
7. Power Indicator
8. Door Handle
9. Viewing Window
10. Grill Rack
11. Backing Tray
12. Baking Tray Handle
3
4
5
6
1
7
8
9
