11
Espresso Maker
Model No. SDA2698
User Manual
IMPORTANT RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Place one hand on the top of the espresso maker to support the unit and attach
the Coffee Filter Holder (14) using the Filter Holder Handle (10) by holding the
handle and placing it in the coffee maker as in fig.3 then rotate right to the
locked position as shown below in fig.4:
4. Ensure that the Steam Control (6) is set to the OFF position. Place a cup onto
the Drip Tray Plate (11).
5. Insert the mains plug into the nearest socket.
6. Press the Power Button (2), the power button will flash whilst the unit is
warming up.
7. Once the button has stopped flashing, the Power Button (2) and the Brewing
Button (4) will both illuminate to show the espresso maker has warmed up.
8. Press the Brewing Button (4) which will start the brewing process and hot
water will be dispensed into the cup. Be careful not to overfill the cup.
9. Press the Brewing Button (4) to stop brewing once the cup is full.
10. Carefully empty the cup once full.
NB the Brewing Button (4) will flash during the brewing process.
Fig. 3
Fig. 4
