3
MECHANICAL GEARBOX CONTROL
Removal and installation CF65/75/85 series
3-8
2. Press the locking plate and spring down
and fit the four attachment bands in the
bearing cover slots.
3. Fit the gear lever with the bearing to the
bearing cover and fit the snap ring.
4. Secure the gaiter by means of the lips.
These must be pulled through the slots in
the locking plate.
5. Fit the selector rod.
6. Connect the air pipes. Ensure that the pipes
are clear of any moving parts.
7. Check that the pneumatic system is airtight.
8. Check that all switches, both mechanical
and pneumatic, function properly.
W 302057
V300405
W 302059
2
ᓻ 0111
