3
CF65/75/85 series Removal and installation
MECHANICAL GEARBOX CONTROL
3-11
3.5 REMOVAL AND INSTALLATION, CONTROL ROD
Removing the control rod
1. Make sure there are no loose items in the
cab. Tilt the cab.
2. After marking them, remove the air pipes
that run from the switch to the various
valves.
3. Remove the lock nut (4) from the torque rod
ball joint and remove the torque rod from
the control rod.
4. Remove the castle nut from the ball joint on
the gearbox lever and remove the control
rod.
5. Remove the clamping bolt (1) and remove
the control rod (2) from the gear lever unit.
V300407
4
5
312
V300275
2
ᓻ 0111
