3
ZF 8/9/16S-109 GEARBOX
Removal and installation, gearbox CF65/75/85 series
4-4
5. Apply a suitable locking compound between
the rear of the washer (1) and the drive
flange. See “Technical data”.
6. Install the locking plate with the bolts and
tighten them to the specified torque. See
“Technical data”.
Note:
Bolts that will be re-used must be cleaned
and lightly oiled.
7. Fit a new locking plate (DAF No. 0699725)
with stamp over the bolt heads.
1
V300356
6
ᓻ 0111
