3
EATON FS/6309A GEARBOX
Removal and installation, gearbox CF65/75/85 series
3-2
Installing the gearbox
1. Engage the highest gear in order to align
the keys of the input shaft with the clutch
plate.
2. Fit the gearbox to the engine. If necessary,
rotate the drive flange in order to align the
keys.
3. Fit the gearbox attachment bolts all around
and tighten them to the specified torque.
See “Technical data”.
4. Fit the shift control.
Tighten the nuts to the specified torque.
See “Technical data”.
5. Fit the exhaust intermediate pipe.
6. Fit the exhaust end pipe.
7. Install the compressor pipe bracket.
8. Install the electrical connectors to the
gearbox.
9. Fit the clutch cylinder and tighten the
attachment bolts to the specified torque.
See “Technical data”.
10. Fit the air pipes.
11. Fit the prop shaft flange to the gearbox.
Tighten the attachment bolts to the
specified torque. See “Technical data”.
12. Connect the negative lead to the battery
terminal.
13. Inspect the shift control.
14. Check the oil level after the gearbox has
been installed.
15. If a gearbox of a different type is mounted,
or a gearbox with a different reduction, this
should be reported.
If the correct data are present, they can be
input into the VIC using DAVIE XD.
8
ᓻ 0111
