CF65/75/85 series Removal and installation, gearbox
EATON FS/6309A GEARBOX
3-3
3.2 REMOVAL AND INSTALLATION, DRIVE FLANGE
Removing the drive flange
1. Place a reference mark on the prop shaft in
relation to the flange.
2. Remove the bolts that attach the prop shaft
to the flange.
3. Support the prop shaft from a suitable
location on the chassis.
4. Support the prop shaft from a suitable
location on the chassis.
5. Fit special tool (DAF No. 0484977) to hold
the drive flange in position. Remove the
lock nut and ring.
6. Remove the flange with a suitable puller.
Note:
In order to prevent the synchroniser for the
high/low transmission ratios from coming
loose, the output shaft must not slide out of
the bearing.
Installing the drive flange
1. Place the flange on the output shaft.
2. Place a shim between the flange and the
lock nut and turn the flange in the oil seal.
Remove the lock nut and shim.
3. Fit special tool (DAF No. 0484977) to the
flange. Fit a new lock nut. Tighten the lock
nut to the specified torque. See “Technical
data”.
4. Align the markings. Fit the prop shaft to the
flange. Tighten the attachment bolts to the
specified torque. See “Technical data”.
