3
EATON FS/6309A GEARBOX
Removal and installation, gearbox CF65/75/85 series
3-4
3.3 REMOVAL AND INSTALLATION, OUTPUT SHAFT OIL SEAL
Removing the output shaft oil seal
1. Remove the drive flange.
2. Remove the attachment bolts from the oil
seal housing. Remove the oil seal housing.
Remove the oil seal.
3. Clean the contact surfaces of the oil seal
and the seal housing.
Installing the output shaft oil seal
1. Press the oil seal into its housing with
special tool (DAF No. 1329358).
2. Apply sealant to the contact surface of the
oil seal housing.
3. Fit the sealing housing and tighten the bolts
to the specified torque. See “Technical
data”.
4. Apply grease to the lip of the oil seal.
5. Fit the drive flange.
6. If necessary, top up the gearbox. See
“Technical data”.
8
ᓻ 0111
