DAF CF75 Series - Page 264

3
EATON FS/6309A GEARBOX
Removal and installation, gearbox CF65/75/85 series
3-6
3.5 REMOVAL AND INSTALLATION, SELECTOR SHAFT OIL SEAL
Removing the selector shaft oil seal
1. Remove the nut (4) of the ball joint of the
control rod on the selector shaft lever and
the nut (5) of the torque rod.
Hang the control rod on the chassis.
2. Remove the selector shaft lever locking
bolt. Then remove the selector shaft lever
(1) together with the rubber sleeve (2).
V300407
4
5
1
20
2
3
4
8
5
14
6
9
10
15
16
17
18
19
12
11
13
7
V3 00 475
8
ᓻ 0111
