CF65/75/85 series Removal and installation, gearbox
EATON FS/6309A GEARBOX
3-7
3. Drain the air reservoirs and remove the air
connection from the selector shaft housing.
4. Remove the bleed control valve and
pin (16).
5. Remove the attachment bolts from the
selector shaft housing (15) and remove the
housing.
6. Place the housing in a soft-jawed vice.
7. Remove the retaining cover (5) and pull out
the retaining spring (6) and pin (7).
8. Remove the bleeder (20).
9. Remove the end cover (14) and remove the
circlip (13).
10. Remove the spring holders (11), the springs
(12) and the circlip (10).
11. Turn the selector shaft housing over and
drive the plug (8) out of the housing.
12. Turn the selector shaft housing over and
drive the plug, pin (19) out of the selector
finger (18) and selector shaft housing (17)
via the opening.
13. Remove the selector finger (18) and the
selector shaft (17).
14. Remove the oil seal (3) from the selector
shaft housing. If necessary, the selector
shaft bearing bushes (4) and (9) can now
also be removed using a suitable puller.
