DAF CF75 Series - Page 266

3
EATON FS/6309A GEARBOX
Removal and installation, gearbox CF65/75/85 series
3-8
Installing the selector shaft oil seal
1
20
2
3
4
8
5
14
6
9
10
15
16
17
18
19
12
11
13
7
V3 00 475
1. Fit a new oil seal ring and, if necessary, new
bushes (4) and (9) using special tool
(DAF No. 1329352).
2. Place the selector finger (18) in the selector
shaft housing (15) with the long groove and
the hole for the pin (19) pointing towards the
rear.
3. Fit the selector shaft (17) into the selector
shaft housing,
V3 00 498
88
ᓻ 0111
