3
CF65/75/85 series Removal and installation
CLUTCH
5-5
4. Check whether the retainer plate (2) and
circlip (1) and retaining clip (3) have been
fitted in the correct locations. The
diaphragm springs (4) have special
recesses to accommodate the retaining
clips (3).
V300122
2
4
4
1
3
3
5. Fit the gearbox.
6. Move the clutch lever so as to lock the
thrust bearing in the clutch release
assembly.
V300442
10
ᓻ 200337
