3
CF65/75/85 series Removal and installation
CLUTCH
5-15
5.9 REMOVAL AND INSTALLATION, PILOT BEARING
Removing the pilot bearing
1. Remove the gearbox.
2. Remove the clutch release assembly and
the clutch plate.
3. Use an internal puller (2) to remove the pilot
bearing (1) from the flywheel.
W 3 04 016
1
2
Fitting the pilot bearing
1. Check the flywheel bore for dirt and
damage.
2. Note:
The pilot bearing (1) has a grease and dust
seal (2) on one side only. When the pilot
bearing is fitted, the grease and dust seal
must be on the clutch plate side.
W 3 04 019
1
2
3. Use a plastic mallet to fit the bearing in the
flywheel.
4. Fit the clutch release assembly and the
clutch plate.
5. Fit the gearbox.
W 3 04 017
10
ᓻ 200337
