3
CLUTCH
Removal and installation CF65/75/85 series
5-16
5.10 REMOVAL AND INSTALLATION, MAIN CYLINDER
Hydraulic fluid is toxic and can
therefore have a damaging effect on
your health.Hence avoid any direct
or indirect physical contact. As
hydraulic fluid is also a corrosive
fluid, it may damage the paintwork
of the vehicle. Avoid any contact
between hydraulic fluid and
paintwork.
Always use new and clean hydraulic
fluid which has been kept in a
sealed container that meets the
specifications. Hydraulic fluid which
has absorbed water (from the
ambient air) may have an adverse
effect on the operation of the clutch
system.
Avoid any contact with mineral oil.
Even one drop of mineral oil in the
system will damage the seals.
Removing the main cylinder
1. Connect a transparent plastic hose to the
clutch servo’s bleed nipple.
2. Open the bleed nipple (collect the fluid) and
drain the system.
3. Remove the clutch spring from the clutch
pedal.
4. Remove the attachment bolt from the clutch
pedal and the main cylinder.
5. Remove the pipe between the reservoir and
the main cylinder.
6. Disconnect the fluid pipe at the bottom of
the main cylinder.
7. Remove the two attachment bolts from the
main cylinder and take the cylinder from the
bracket.
V300443
10
ᓻ 200337
