AS TRONIC GEARBOX
Removal and installation CF65/75/85 series
4-14
4.5 REMOVAL AND INSTALLATION, OUTPUT SHAFT OIL SEAL
Removing the output shaft oil seal
1. Remove the prop shaft from the gearbox
flange and hang it on the chassis.
2. Remove the drive flange.
3. Drill two holes into the external cover of the
oil seal and turn the special tool
(DAF No. 0484899) into the oil seal. Then
pull the oil seal out of the bearing cover
using the special tool (DAF No. 0694928).
Installing the output shaft oil seal
1. Apply methylated spirit to the outer
circumference of the oil seal. Apply a little
grease to the sealing lip.
2. Fit the oil seal into the bearing cover using
the special tool (DAF No. 1453146 in
combination with 1453148).
3. Fit the drive flange.
4. Attach the prop shaft.
14
ᓻ 200337
