3
CF65/75/85 series Removal and installation
MECHANICAL GEARBOX CONTROL
3-5
Installing the gear lever gaiter
1. Slide the gaiter over the gear lever.
2. Fit the ball.
3. Fit the entire gear lever to the shift unit and
lock it with the specific Seeger ring.
4. Secure the gaiter by means of the lips.
These must be pulled through the slots in
the locking plate.
5. Feed the air pipes through the gear lever
and fit the switch with the valve to the gear
lever. Tighten the threaded bush and slide
the gaiter over the threaded bush.
6. Fit the selector rod.
7. Connect the air pipes. Ensure that the pipes
are clear of any moving parts.
8. Check that the pneumatic system is airtight.
9. Check that all switches, both mechanical
and pneumatic, function properly.
W 302059
W 302069
2
ᓻ 0111
