3
MECHANICAL GEARBOX CONTROL
Removal and installation CF65/75/85 series
3-6
3.3 REMOVAL AND INSTALLATION, GEAR LEVER UNIT INNER DUST COVER
Removal, gear lever unit inner dust cover
1. Remove the entire gear lever unit from the
bracket.
2. Loosen the gaiter from the locking plate by
lifting the gaiter and pulling the gaiter lips
away from the locking plate.
3. Then remove the Seeger ring that has
become visible from the bearing cover. It is
now possible to remove the entire gear
lever from the bearing cover.
4. Press the locking plate down and slide the
four attachment bands from the bearing
cover slots.
W 302059
V300405
W 302057
2
ᓻ 0111
