DAF CF85 Series - 3.2 INSPECTION AND ADJUSTMENT, AXIAL PLAY OF DRIVE SPROCKETS IN FLYWHEEL HOUSING OF DAF ENGINE PTO

3
CF65/75/85 series Inspection and adjustment
PTO
3-3
3.2 INSPECTION AND ADJUSTMENT, AXIAL PLAY OF DRIVE SPROCKETS IN
FLYWHEEL HOUSING OF DAF ENGINE PTO
Inspection and adjustment, axial play of
drive sprockets in flywheel housing
Note:
The procedures apply to both sets of drive
sprockets.
1. Press both outer bearing races (4) into the
drive sprocket (1).
V300637
1
4
2. On one side of the drive sprocket, mount
the inner bearing race.
3. Place the drive sprocket on the inner race
on a driving tool underneath a press.
Note:
The external diameter of the driving tool (1)
and the diameter of the inner bearing race
(2) must be the same.
Furthermore, when the play is checked, the
shims must remain centred on the inner
race.
V300641
2
1
13
ᓻ 200337
