200515 7-1
Lubrication
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
ΛΦ45/55 series
5
7. LUBRICATION
7.1 LUBRICATING ACCORDING TO Y-SERVICE LUBRICATION SCHEDULE
Note:
The lubricating points marked below with an (S)
indicate that the lubricating point is positioned on
both the left-hand and right-hand side of the
vehicle.
Lubricating stub axles (S), general
1. To make sure that the grease can penetrate
adequately, the stub axles should be
lubricated in unloaded condition. The front
axle should therefore be completely jacked
up; make a complete steering movement
from left to right during greasing.
2. Lubricate the stub axles until grease comes
out.
F36, F48 and F60 (S) front axles
1. The F36 and F48 front axles have a grease
nipple on the top side and the underside. The
F60 front axle has a grease nipple only on
the underside.
S7 00 545
S7 00 591
S7 00 590
