EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-4
©
200515
Removal and installation
5
ΛΦ45/55 series
4.4 REMOVAL AND INSTALLATION, FUEL FINE FILTER
When removing the fuel fine filter, a
quantity of fuel will escape. Collect
the fuel and avoid the risk of fire.
Removing the fuel fine filter
1. Place a container beneath the fuel fine filter
and remove the filter.
Note:
The fuel fine filter is a disposable filter and
must therefore not be cleaned and re-used.
Installing the fuel fine filter
Note:
Do not fill the fine filter with fuel until it has
been fitted. The fine filter is filled with fuel by
the primer pump after it has been fitted. This
considerably reduces the risk of dirt getting
into the fuel system.
1. Check by hand whether the coupling piece
for the filter attachment is securely attached.
2. Lightly lubricate the filter sealing ring with
clean engine oil.
3. Fit the filter element onto the housing.
Tighten the filter element until the sealing
ring abuts. Tighten the filter element a further
∂ to • turn by hand.
4. Bleed the fuel system. See "Inspection and
adjustment".
5. Start the engine and check the fuel system
for leaks. If necessary, retighten the filter by
hand.
}
G0 00 201
i400964
