DAF XF105 - Lighting and Gearbox Controls

2
1
1 2
2
1
Manual gearbox
H-pattern 4 low range, 4 high range:
1 (Pre)select range at front side gearlever.
2 Half ranging (splitting) at the side of
the gearlever.
Automated gearbox
N Neutral.
D Drive.
R Reverse.
Forward/reverse manoeuvring
positions (adjusted gas throttle
settings for slow, flowing movement.
Limited torque/rev and clutch slip).
Lighting switch
1 Parking and marker lights on.
2 Headlamps, parking and
marker lights on.
1 AS-Tronic and MX engine brake.
• Engine brake on/off (accelerator
pedal usage overrules setting, gear
changing not).
• Auto/manual (use twice for search
in manual).
• Shift up/down (one click - one
gear, double click – two gears).
2 AS-Tronic and Intarder.
• AS-Tronic use similar.
• 1/3, 2/3, full intarder operation.
7 DAF XF105 QUICK GUIDE
