User’s Manual
220
Parameter
Description
Name Enter the customized rule name.
Action
Configure the actions that are defined as intrusion. You can select the
Appear
checkbox and the
Cross
checkbox.
Direction
In the
Direction
list, select the direction of crossing the configured area.
You can select
Enter&Exit
,
Enter
, and
Exit
.
Target Filter
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum size).
When the target that is crossing the tripwire is smaller than the minimum
size or larger than the maximum size, no alarms will be activated. The
maximum size should be larger than the minimum size.
Effective Target
Enable the AI Recognition function ( ). By default,
Human
and
Motor Vehicle
are selected for alarm object.
4) Drag to draw an area.
5) Click
OK to save the settings.
Click to set the actions to be triggered.
Select the Enable checkbox, and then click Apply.
The intrusion detecting function is active. When the target enters and leaves the area, or the
target appears in the defined area, the system activates alarms.
5.11.3.2.2 Smart Search for IVS Function
You can search for the intelligent events and play back.
Select Main Menu > AI > AI Search > IVS.
IVS
In the Channel list, select the channel that you want to search for the events, and then set
other parameters such as start time, end time, event type, and alarm object.
Click Smart Search.
