User’s Manual
152
Parameter
Description
Alarm-out Port
Click
Setting
to display setting page.
Local Alarm: Enable alarm activation through the alarm devices
connected to the selected output port.
Extension Alarm:
Enable alarm activation through the connected
alarm box.
Wireless Siren: Enable alarm activation through devices connected
by USB gateway or camera gateway.
Post-Alarm
Set a length of time for the Device to delay turning off alarm after the
external alarm
is cancelled. The value ranges from 0 seconds to 300
seconds, and the default value is 10 seconds.
Show Message
Select the
Show Message
checkbox to enable a pop-up message in your
local host PC.
Report Alarm
Select the
Report Alarm
checkbox to enable the system to upload the
alarm signal to the network (including alarm center) when an alarm event
occurs.
Send Email
Select the
Send Email
checkbox to enable the system to send an email
notification when an alarm event occurs.
To use this function, make sure the email function is enabled in
Main
Menu > NETWORK > Email
.
Record Channel
Select the channel(s) that you want to record. The selected channel(s)
starts recording after an alarm event occurs.
The recording for local
alarm recording and auto recording must be
enabled. For details, see "5.1.4.9
Configuring Recorded Video Storage
Schedule" and "5.9.1 Enabling Record Control."
PTZ Linkage
Click
Setting
to display the PTZ page.
Enable PTZ linkage actions, such as selecting the preset that you want to
be called when an alarm event occurs.
Post Record
Set a length of time for the Device to delay turning off recording after the
alarm is cancelled. The value ranges from 10 seconds to 300 seconds, and
the default value is 10 seconds.
Tour Select the
Tour
checkbox to enable a tour of the selected channels.
Picture Storage
Select the
Snapshot
checkbox to take a snapshot of the selected channel.
To use this function, select
Main Menu > CAMERA > Encode > Snapshot
,
in the
Type
list, select
Event
.
Sub Screen
Select the checkbox to enable the function. When an alarm event occurs,
the extra screen outputs the settings configured in
Main Menu >
DISPLAY > Tour Setting > Sub Screen.
 Not all models support this function.
 To use this function, extra screen shall be enabled.
