Dahua Technology DH-XVR71 H-4K-I2 Series User Manual

User’s Manual
132
Type list
Click Apply to save the settings.
 If you have configured the snapshot schedule, the configuration has been completed.
 If you have not configured the snapshot schedule, see "5.1.4.10 Configuring Snapshot
Storage Schedule."
5.8.1.2 Configuring Event Triggered Snapshot
Select Main Menu > CAMERA > Encode > Snapshot.
In the Type list, select Event, and then configure other parameters.
Event
Select Main Menu > ALARM > Video Detection, and select the event type to configure, for
example, select the Motion Detection tab.

Dahua Technology DH-XVR71 H-4K-I2 Series Specifications

General

Brand	Dahua Technology
Model	DH-XVR71 H-4K-I2 Series
Category	DVR
Language	English
