User’s Manual
5
Components 2.3
Components Figure 2-4
Table 2-1 Description of components
No. Description
No. Description
1 Cover
9 Lever
2 Spring rod 10 Base
3
Driven counterweight rocker arm 11 Motor
4 Mainshaft 12 Driving rocker arm
5
Connecting rod 13 Casing
6
Counterweight spring 14 Controller
7
Power supply 15 Ground
8 Door
— —
