4
User’s Manual
DHI-LM27-E331A
Figure 2-2 Monitor adjustments
NOTE
When adjusting the angle of the monitor, be sure not to touch or press the area of the screen.
The above figure is for reference only, and everything is subject to the actual adjustment function.
-
5
90mm
° 20°
Tilting angle
5.0°(±3.0°) ~ - 20°(±3.0°)
Height adjustment
90mm( - 5.0mm)
Rotation angle
±20°( -3.0°)
