User's Manual
153
Intrusion rule
3) Configure the settings for the parameters of drawing rules.
Table 5-40 Rule parameters
Name Enter the customized rule name.
Action
Configure the actions that are defined as intrusion. You can select the
check box and the
check box.
Direction
In the
list, select the direction of crossing the configured
area. You can select
,
, and
.
Filtering Target
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum
size). When the target that is crossing the tripwire is smaller than the
minimum size or larger than the maximum size, no alarms will be
activated. The maximum size should be larger than the minimum size.
4) Drag to draw an area.
5) Click
Save to save the settings.
Click to set the actions to be triggered. For details, see "5.10.2.1 Configuring Tripwire
Rules."
Select the Enable check box, and then click Apply.
