User's Manual
12
This is only needed on models with 8 bays.
Fix drive brackets
Put the drive brackets back and fix them in the DVR.
Put back drive bracket
Connect the disks and the DVR with power cable and data cable.
The following figure shows the connection of 4-bay model for example.
Connect cables
Put the cover back and fasten the screws.
