User's Manual
213
5.14.1.9 Configuring Multicast Settings
When you access the Device from the network to view the video, if the access is exceeded, the video
will not display. You can use the multicast function to group the IP to solve the problem.
Select Main Menu > NETWORK > MULTICAST.
Multicast
Configure the settings for the multicast parameters.
Table 5-66 Multicast parameters
Enable Enable the multicast function.
IP Address
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.
Port
Enter the port for the multicast. The port ranges from 1025 through
65000.
Click Apply to complete the settings.
You can use the multicast IP address to log in to the web.
On the web login dialog box, in the
Type list, select MULTICAST. The web will automatically
obtain the multicast IP address and join. Then you can view the video through multicast
function.
