User's Manual
79
Configure the settings for the tour parameters for both Main Screen and Extra Screen.
Table 5-18 Screen parameters
Parameter
Description
Enable Enable tour function.
Interval (Sec.)
Enter the amount of time that you want each channel group displays on
the screen. The value ranges from 5 seconds to 120 seconds, and the
default value is 5 seconds.
Video Detect,
Alarm
Select the View 1 or View 8 for
Motion Detect
tour and
Alarm
Tour
(system alarm events).
Window Split
In the
Window Split
list, select
View 1
,
View 4
,
View 8
, or other modes
that are supported by the Device.
Channel Group
Display all channel groups under the current Window Split setting.
Add a channel group: Click
Add
, in the pop-up
Add Group
channel,
select the channels to form a group, and then click
Save
.
Delete a channel group: Select the check box of any channel group,
and then click
Delete
.
Edit a channel group: Select the check box of any channel group and
then click
Modify
, or double-click on the group. The
Modify Channel
Group
dialog box is displayed. You can regroup the channels.
Click
Move up
or
Move down
to adjust the position of channel group.
Click Apply to save the settings.
On the upper-right of the live view screen, use the left mouse button or press Shift to
switch between (image switching is allowed) and (image switching is not
allowed) to turn on/off the tour function.
On the navigation bar, click to enable the tour and click to disable it.
Adding a Channel Group
Click Add.
The Add Group interface is displayed.
Add group
